DAHUA ITSJC-2303-DC12 Anti-smashing Radar
The DAHUA ITSJC-2303-DC12 Anti-smashing Radar is a high-precision radar sensor designed to prevent collisions between barrier arms and vehicles or pedestrians in automated access systems. Operating at a 79 GHz frequency with advanced signal processing, it offers stable and accurate detection that enhances safety in parking lots, gated communities, commercial premises, and other access control environments.
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Key Features
-
79 GHz radar technology with high-precision FMCW signal processing.
-
Adjustable detection range and width (0.3 m–6 m).
-
Anti-smashing zone adjustable (0 m–2 m) to protect vehicles and users.
-
Detects both humans and vehicles.
-
Online commissioning and firmware update via serial port or mobile app.
-
RS-485 integration for communication with access control cameras or systems.
-
IP66 weather-proof rating for reliable outdoor operation.
-
Compact and lightweight for easy installation on barrier systems.
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Specifications
| Specification | Details |
|---|---|
| Product Name | DAHUA ITSJC-2303-DC12 Anti-smashing Radar |
| Emission Frequency | 77 GHz–81 GHz |
| Emission Power | ≤ 10 mW |
| Beam Width | Vertical: ± 10°, Horizontal: ± 36° |
| Response Time | 50 ms |
| Detection Region | 0.3 m–6 m (adjustable) |
| Anti-smashing Region | 0 m–2 m (adjustable) |
| Detection Target | Human & Vehicle |
| Ports | 1 × RS-485, 2 × I/O (1 update input, 1 relay output) |
| Operating Voltage | 9 V–12 V DC |
| Operating Current | < 0.25 A |
| Power Consumption | < 3 W |
| Operating Temp. | –40 °C to +85 °C |
| Protection Grade | IP66 (weather-proof) |
| Dimensions | 96 × 60 × 16.4 mm (L×W×H) |
| Net Weight | ~70 g |
| Installation | Side-mount on barrier or housing |
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Price in Kenya
| Product | Price Range |
|---|---|
| DAHUA ITSJC-2303-DC12 Anti-smashing Radar | KSh 20,000 – KSh 26,000 |
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Design and Build
-
Compact radar module designed for mounting on barrier systems.
-
IP66 weather-proof housing suitable for outdoor environments.
-
LED indicators and simple wiring via RS-485 and I/O for easy integration with access control systems.
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Performance
-
Fast response time (50 ms) ensures rapid detection and anti-collision action.
-
Adjustable detection and anti-smash parameters adapt to various installation scenarios.
-
FMCW radar technology provides accurate detection of vehicles and pedestrians even in complex scenes.
-
Integration with Dahua cameras lets you view radar logs and parameters remotely.
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Ideal User Cases
-
Vehicle access control points with automated barriers.
-
Parking lots and gated communities requiring anti-crash protection.
-
Commercial and institutional entrances where safety against collisions is critical.
-
Integration with CCTV and control systems for enhanced safety monitoring.
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Safety Measures
-
Ensure stable mounting on barriers to avoid false detection due to vibration.
-
Keep the installation area free from obstruction to maintain accurate detection.
-
Protect wiring and RS-485 connections from moisture and physical damage.
-
Update firmware through official tools or mobile app for latest features and bug fixes.
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Pros and Cons
| Pros | Cons |
|---|---|
| High-precision 79 GHz radar detection | Requires correct alignment and installation |
| Adjustable detection & anti-crash zones | Not standalone — works best with barrier systems |
| IP66 outdoor protection | No built-in display/interface |
| RS-485 integration with cameras/systems | May need professional setup |
| Fast response time for collision avoidance | Features more basic vs full radar systems |
DAHUA ITSJC-2303-DC12 Anti-smashing Radar Frequently Asked Questions
1. What does the radar detect?
It detects humans and vehicles within the adjustable range of ~0.3 – 6 m.
2. Does it work outdoors?
Yes — with an IP66 rating, it’s suitable for outdoor installations.
3. How is it powered?
It runs on 9–12 V DC with low power consumption (< 3 W).
4. Can it integrate with existing systems?
Yes — it connects via RS-485 and I/O ports with barriers or cameras for logging and control.
5. Is firmware updatable?
Yes — you can update firmware via serial or mobile app (Wi-Fi).
Conclusion
The DAHUA ITSJC-2303-DC12 Anti-smashing Radar is a robust, high-precision radar sensor that enhances safety around barrier systems by detecting and preventing collisions with vehicles or pedestrians. Its adjustable detection range, fast response, and integration capabilities make it an ideal addition to modern access control and parking setups, delivering reliable performance even in intense outdoor environments.
